typical application
Biopharmaceuticals, food industry, chemical liquid filtration, fluidized bed liquid supply, pharmaceutical industry transfer, biocatalyst transmission, etc.
main feature
Large traffic transmission
The pump head adopts aluminum alloy shell and 304 stainless steel roller assembly
Driven by a high-power AC geared motor, an external inverter can be used to adjust the flow
The pressure pipe gap can be adjusted to extend the life of the pipe.
Biopharmaceuticals, food industry, chemical liquid filtration, fluidized bed liquid supply, pharmaceutical industry transfer, biocatalyst transmission, etc.
main feature
Large traffic transmission
The pump head adopts aluminum alloy shell and 304 stainless steel roller assembly
Driven by a high-power AC geared motor, an external inverter can be used to adjust the flow
The pressure pipe gap can be adjusted to extend the life of the pipe.
| Flow range | 1.5-40L/min | Speed adjustment range | 30-350rpm |
| Speed resolution | 0.6RPM | Applicable power supply | AC 380V±10% 50Hz/60Hz |
| Power consumption | ≤400W | working environment | 0-40℃ Humidity＜80% |
| Dimensions | 700*320*369mm | Total Weight | 46.65kg (without frequency converter) |
| Protection level | IP55 |
| driver | Applicable hose | Maximum reference flow range | Speed range (rpm) |
| FB350S&KZ48 | (L/min) | ||
| 88# | 1.5-15 | 30-350 | |
| 92# | 3-40 |
